TB Thick Type Fire-Resistive And Heat-Isolating Coating
  • TB Thick Type Fire-Resistive And Heat-Isolating Coating
  • Specifications
    • Product Name:TB Thick Type Fire-Resistive And Heat-Isolating Coating
    • Product Number:TB
    • 分享到:
  • Details
  • >Product introduction

    TB thick fireproofing and heat-isolating coating is developed by Tabard. It is made by inorganic material and it has the highest quality in the world. It can be used for all kinds of steal building,construction(especially super high level buildings) and the surface of concrete fire protection. It also can be applied for protecting steel structure under the fire caused from petrol-chemicals.



    >Features

     It has no asbestos or organic solvent and harmless.

     It can be applied by spray or paint, and quickly solidify.

     Light coating, quick adhesion, high strength and anticorrosive resistance.

     Excellent fire resistance and climate resistance characteristic.

     Do not need to do anticorrosion when necessary.



    >Application

     Clean the surface be fore applying.

     It is a dry powder prouduct. Mix with water under certain two and half hours.See the work instruction for more drtail.

     Product must be used within one day after opened.

     The temperature should be above 0℃. It needs at least 28 days to gain the best performance.

     Needed the professional or trained people to do the application.



    >Storage and Transportation

     The TB coating is nonpoisonous and innocuous.It does not ignite or explode.therefore it can be transported as normal materials.It should be stored at 5-35℃ temperature and kept in cool,dry and ventilate place. It is effective for 6 months.


    Main technical indicator

    Item Indicator
    Drying time(surface drying,h) <=24
    Anti-cracking performance at primary of drying Allow 1-3 flaws and the width<=1mm
    Binding Strength (Mpa) >=0.04
    Pressing Strength(MPa) >=0.05
    Dry Density (kg/m³)<=650
    insolate resistance(h) >=720
    wet and heat resistance(h) >=504
    freeze-thaw-stability(times) >=15
    acid resistance(h) >=360
    alkali resistance(h) >=360
    salt fog and canker resistance(times) >=30
    Fire-resistance performance Coating thickness(mm) 10 14 19 25
    Fire-retardant ratings(min) >=90 >=120 >=150 >=180
